Quick disconnect waterproof connector L16, 3 pins, 16A, IP68, 1 pc.

Aрт. № KWS3PL16
Quick disconnect waterproof connector L16, 3 pins, 16A, IP68, 1 pc.
Quick disconnect waterproof connector L16, 3 pins, 16A, IP68, 1 pc. Quick disconnect waterproof connector L16, 3 pins, 16A, IP68, 1 pc. Quick disconnect waterproof connector L16, 3 pins, 16A, IP68, 1 pc.

Quick disconnect waterproof connector L16, 3 pins, 16A, IP68, 1 pc.

Art № KWS3PL16
description:

A new model connector with the integrated plug connection/disconnection and following advantages:

  • Quick terminals for easy connection of wires with cross section from 0.75 to 2.5 mm² (no instruments needed).
  • Integrated plug connection/disconnection.
  • Suitable for multi and single core cables with max. diameter 11 mm.
  • Housing made of UV-stable and fire-retardant polyamide (PA66).
  • High ingress protection rate IP68.
  • Wide work temperature range – from -40°C to +85°C
  • Could be used for power supply lines with max. current load 16 A AC.

Usage:

  • Industrial lighting;
  • Street lighting;
  • Garden lighting;
  • Exterior lighting;
  • Lighting projects.
specifications:
Maximum current 16A
Maximum Voltage AC 250V
Dielectric Resistance 500 mΩ/ 500V
Breakdown Voltage 3kV
Protection rating IP68
Working temperature range -40 ⁰C ÷ до +85 ⁰C
Dimensions 110/29mm
Cross section of the cables 0.75 до 2.5mm²
Cable diameter 11 mm
Polarity 3 pins
description:

A new model connector with the integrated plug connection/disconnection and following advantages:

  • Quick terminals for easy connection of wires with cross section from 0.75 to 2.5 mm² (no instruments needed).
  • Integrated plug connection/disconnection.
  • Suitable for multi and single core cables with max. diameter 11 mm.
  • Housing made of UV-stable and fire-retardant polyamide (PA66).
  • High ingress protection rate IP68.
  • Wide work temperature range – from -40°C to +85°C
  • Could be used for power supply lines with max. current load 16 A AC.

Usage:

  • Industrial lighting;
  • Street lighting;
  • Garden lighting;
  • Exterior lighting;
  • Lighting projects.
